**Comments**
One of my most favorite area for narrowband, I had to come back with the CDK12.5 system. Still working on the star flairs but much better than before plus collimated the scope better.
* Astrobin: https://app.astrobin.com/i/cxlhi0
**Moon Phase, Light Pollution Level, and Date**
* Average Moon Phase: 59%
* Bortle 7
* September 29, 30, 2025
* October 2, 3, 4, 8, 11, 12, 19 20, 2025
**Equipment**
* Telescope/Lens: **Planewave CDK 12.5 (2541mm at F/8)**
* Flattener/Reducer: N/A
* Auto Focuser: Planewave Hendrick Focuser
* Focuser Controller: Planewave Electronic Focus Accessory (EFA) Kit
* Filter: **Chroma 50mm SHO 3nm Telescope Filter – Unmounted**
* Filter Wheel: ZWO EFW (7 x 50mm)
* Mount: **Astro-Physics Mach 1600 GTO**
* Guide Scope: OAG: ZWO OAG-L
* Guider: ZWO ASI174MM-MINI
* Dew Heater Controller: Pegasus Astro Pocket Powerbox Advance (Clean up Cables)
* Dew Heater Controller: Planewave Delta T Heater
* Dew Heaters: Two on CDK 12.5 built into the scope
* Camera: **ZWO ASI6200mm Pro **
* Polar Alignment: QHYCCD Polemaster (Precise polar alignment)
* Intel NUC (For imaging, dither, auto guiding, plate solve)
**Software**
* PHD2 (For Auto Guiding)
* QHYCCD PoleMaster Software (Polar Alignment)
* Nighttime Imaging ‘N’ Astronomy (NINA) (Automation with Dithering, plate solving, mount control)
* Astro-Physics ASCOM V2 (AP 1600GTO Control)
* Pegasus Astro Pocket Powerbox (Control the Powerbox Advance)
* Planewave Interface 3 (PWI 3) (Controllers focuser, scope fans, dew heaters)
* Photoshop (Processing)
* PixInsight (Calibration & Processing)
**Acquisition**
* Total Exposure: **40 Hours**
* Chroma SII – 192 x 300s (**16 hrs**)
* Chroma HA – 96 x 300s (**8 hrs**)
* Chroma OIII – 192 x 300s (**16 hrs**)
* Temperature: -5°C and -10°C
* Flats: 20 to 60
* Darks: N/A
* Bias: 200
* Gain: 100
* Offset: 50
* Bin: 1×1
* Pixel Scale: 0.31″/pixel
**Processing in Photoshop and PixInsight**
PixInsight
* Subframe Selector
* Image Calibration
* Star Alignment
* Blink
* Image Integration
* RC-Astro BlurXTerminator
Photoshop
* RC-Astro StarXTerminator
* RC-Astro NoiseXTerminator
* Manual Gradient Adjustment via Masks
* Adjusted levels
* Adjusted Curves
* Selective Curves Adjustment
* Layer set as “Linear Dodge (Add)” to add back the stars
* Color Saturation
* Star Color Correction
* Blacks Correction
* Vibrance Applied
* Clarity Applied
* Dehaze Applied
* Sharpening Applied
* Crop out edge artifacts
